Product Model: | F1622GB |
FOB Price: | US$108-US$118 |
Min. Order: | 1pc |
Product Brand: | IdeaCamera |
OEM/ODM: | Support |
Warranty: | 2 Years |
Country of Origin: | China |
Certificate: | CE,FCC,ROHS |
PDF: |
Model: F1622GB
Key features:
16pcs 10M/100Mbps POE Ports
2pcs 100/1000Mbps Network Port (RJ45)
2pcs SFP 100/1000Mbps ports
IEEE802.3 AF/AT standard
Support IPC and AP Power Supply
Data and power supply over 100Meters
15.4W for each port output, total 250W
Enough power to support almost all of IPC
Backplane bandwidth: 100M
Transmit distance: ≤100M
Power Supply: 250W 52V 4.8A
MOQ: 5pcs
Product | 16 Port POE Power Supply Switch(250W) |
Model | F1622GB |
POE Port | 1 to 16 port support IEEE802.3af/at |
SFP Port | Support |
POE Port Output Power | 15.4W/30W IEEE802.3af/at |
POE Power Supply Method | 1/2+、3/6-(or 4/5+、7/8-) |
POE Whole Power | ≤250W |
POE Standard | IEEE 802.3af/IEEE 802.3at |
POE Type | End-span |
POE Power Transmission Distance | ≤200m |
Network Standard | IEEE 802.3、 IEEE802.3u、802.3x、802.3af/at |
Network Medium | 10/100/1000Mpbs 5 class and above non shielded twisted pair |
Network Signal Distance | ≤150m |
Switch Capability | 7.2Gbps |
Forwarding Mode | Store and forward |
Forwarding Rate | 10BASE-T:14880PPS/port 100BASE-tx:14800pps/port 1001000BASE-T: 1488095pps/port |
MAC Address | MAC Address Table 16K |
Port Function | Power priority mechanism, fast and forward, MAC automatic learning and aging IEEE802.3X Full-duplex and mode and backpressure for Half-duplex mode |
LED Indicator | Each port occupied 1 LINK/ACT.100Mbps, POE Status Indicator, Whole power indicator |
Working Environment | Working Temperature:-10°-- 55°C |
Input Power | AC100-240V 50/60HZ |
Whole Power | ≤250W |
Weight | 3.9kg |
Size | 440mm*285mm*44mm(L*W*H) |
