| Product Model: | RP-H8620-5MP-36X |
| FOB Price: | US$228-US$238 |
| Min. Order: | 1pc |
| Product Brand: | IdeaCamera |
| OEM/ODM: | Support |
| Warranty: | 2 Years |
| Country of Origin: | China |
| Certificate: | CE,FCC,ROHS |
| PDF: |  |
Model: RP-H8620-5MP-36X
Key features:
High performance chip (Sony IMX335 CMOS+ HI3516A).
5MP PTZ High Speed Dome IP Camera.
36X Optical Zoom Lens (4.6-165mm).
Efficient Resolution: 2592(V)*1944P (H).
H.264/H.265M Video Compression.
10PCS IR LED+5PCS Laser LED, 150M IR Distance.
Rotation Range (Pan: 0°~360°, Tilt: 0°~93°).
Rotation Speed (Pan: 0~200°/s, Tilt: 0~100°/s).
Auto Flip: Horizontal 180°, Vertical 93°.
Support P2P function.
10" full metal body construction, IP66.
Optional function: Audio
ONVIF; Compatible with HIKVISION, DAHUA, Raysharp, TVT, AEVISION NVR etc.
Camera | |
Solution | 1/2.8" CMOS 5MP Hi3516E+Sony335 |
Output Pixel | 2560*1920@20fps |
Lens | 36X f=4.6mm~165mm, optical zoom |
Illumination | Color: 0.02Lux B/W:0.002Lux |
BLC | Support |
AGC | Auto/manual |
WB | Auto/manual/indoor/outdoor |
DNR | 2DNR, 3DNR |
WDR | DWDR |
S/N Ratio | ≥50dB |
Dome | |
Communications Protocol | TCP/IP, HTTP, NTP, IGMP, DHCP, UDP, SMTP, RTP, RTSP, ARP, DDNS, DNS, HTTPS, P2P |
Software Control | IE, EasyVMS, P6SLite |
Mobile View(optional) | Support Windows, iPhone platform smartphone |
Video compression | H.265/M-JPEG |
Rotation Range | Pan: 0°~360°, Tilt: 0°~93° |
Rotation Speed | Pan: 0~200°/s, Tilt:0~100°/s |
Medium Speed | Pan:0~80°/s, Tilt:0~40°/s |
Auto Flip | Horizontal 180°, Vertical 93° |
Preset Points | 220pcs presets（dwell time 01-60s interval available） |
A-B scan | User programmable (scan speed 1-64 levels setting available) |
Guard Tours | 3 Groups (Max.16 points, dwell time user selectable) |
Operating temperature | -40℃~+60℃ |
Operation menu | English |
Power | DC 12V 5A |
Consumption | ≤20W |
Lightning Protection | Transient voltage 6000V |
IR parameters | |
Auto Control IR LED | PWM |
IR distance | Up to 150meters |
LEDs | 10PCS IR LED+5PCS Laser LED |
