| Product Model: | RP-H86-5MP-36X |
| FOB Price: | US$228-US$238 |
| Min. Order: | 1pc |
| Product Brand: | IdeaCamera |
| OEM/ODM: | Support |
| Warranty: | 2 Years |
| Country of Origin: | China |
| Certificate: | CE,FCC,ROSH |
| PDF: |  |
Model: RP-H86-5MP-36X
Key features:
High performance chip (1/3" CMOS 5MP Hi3516E+Sony335).
5MP PTZ High Speed Dome IP Camera.
36X Optical Zoom Lens (4.5-162mm).
Efficient Resolution: 2592x1944@20fps/2592x1520@15fps.
Rotation Range (Pan: 0°~360°, Tilt: 0°~93°).
Rotation Speed (Pan: 0~200°/s, Tilt: 0~100°/s).
Auto Flip: Horizontal 180°, Vertical 93°.
APP Name：P6SLite
Support P2P function, H.265.
4.5" Total Metal Body Construction, IP66.
6PCS Array 42Mil IR LED+3PCS Laser LED, IR range up to 150M.
ONVIF, Compatible with HIKVISION, DAHUA, Raysharp, TVT, AEVISION NVR etc.
Intelligent IR illumination & power consumption is variable, dependant the zoom factor.
Camera | |
Sensor | 1/3" CMOS 5MP Hi3516E+Sony335 |
Output pixel | 2592x1944@20fps |
Lens | 36X f=4.5mm~162mm |
BLC | Support |
AGC | Auto/Manual |
WB | Indoor/Outdoor/Auto/Manual |
DNR | 2DNR, 3DNR |
WDR | DWDR |
S/N Ratio | ≥50dB |
Dome | |
Communications Protocol | TCP/IP, HTTP, NTP, IGMP, DHCP, UDP, SMTP, RTP, RTSP, ARP, DDNS, DNS, HTTPS, P2P |
Software Control | IE, EasyVMS, P2P(P6SLite) |
Mobile View(optional) | Android, iPhone |
Rotation range | Pan:0~360°, Tilt:0~93o |
Rotation speed | Pan:0~200°/s, Tilt:0~100°/s |
Auto Flip | Horizontal 180o, Vertical 93o |
Preset Points | 220pcs presets（dwell time 01-60s interval available） |
A-B scan | User programmable (scan speed 1-64 levels setting available) |
Guard Tours | 3 groups (Max.16 points, dwell time user selectable) |
video compression | H.265/M-JPEG |
Operating temperature | -40℃~+60℃ |
Operation menu | English |
Power | DC 12V 4A |
Consumption | ≤25W |
Related validation | IP66 |
IR Parameters | |
Auto Control IR LED | PWM |
LEDs | 6PCS Array 42Mil IR LED+3PCS Laser LED |
IR distance | Up to 150 meters |
