Product Model: | |
FOB Price: | US$38.74-US$42.74 |
Min. Order: | 1pc |
Product Brand: | |
OEM/ODM: | |
Warranty: | |
Country of Origin: | China |
Certificate: | CE,FCC,ROHS |
PDF: |
Model: RC-BF75DH-2SWDR
Key features:
2.0-megapixel 3.6mm HD Fixed Lens (4, 6,8mm optional).
4pieces Array LEDs, 40 meters of IR distance.
White casing with strong bracket.
Power In (Internal POE optional).
Key specifications:
32 bit DSP (1/2.8" SONY IMX307 CMOS+ Hi3516Cv300 Sensor).
Maximum resolution 1920*1080@25/30fps.
Day and night all color (without IR Cut).
H.264/H.265 high profile, dual streaming, AVI format, 0.1M~8Mpbs adjustable.
APP Name: VSS Mobile (support IOS, Android).
Standard 38mm*38mm size, convenient and fast for assembling machine.
Support IR_CUT(IR cut filter with auto switch).
Support one channel audio input; one channel audio output; support two-way voice speaking.
Support one channel alarm input; one channel alarm out.
Support one electric zoom interface(-Z model support).
Support one TTL interface.
Support one USB interface.
Support one CVBS interface.
Support one Network lamp interface.
Support Thr-Stream technology.
Support 3D DNR, DWDR.
Support P2P and cross-browser access.
Product Advantages:
Offer 2-years product warranties.
Logistics convenient.
OEM/ODM.
CCC/CE/FCC Certified.
Strict product quality control.
Efficiently working with almost NVR.
Lower price.
6-8 working day per order.
Product applications:
This is the best product of safety field. It and hard disk video recorders、cable、power supply、display、etc. Constitute a complete security system. Tts application is more extensive. Such as homes、factories、highways、office building、garden、community, or a large public places, etc.
2MP WD&SL Single-Boards IP Camera Module | ||
Product model | RC-BF75DH-2SWDR | |
System Structure | DSP | Embedded RTOS, DSP(Hi3516C V300) |
Sensor | 1/2.8" CMOS sensor(SONY IMX307) | |
Video Encoding | Video Encoding | H.265/ H.264High Profile/Main Profile/ Base Line Profile/ MJPEG |
H.265+/ H.264High Profile+/Main Profile+/ Base Line Profile+ | ||
Maximum Image Output | Main stream:1920*1080@25/30fps ; Auxiliary stream 1: 704*576@25/30fps; Auxiliary stream 2: 1280*720@14/3fps ; | |
Streaming transmission | Three stream | |
Video Bite rate | 32Kbps~8MKbps | |
Image Enhancement | Min. illumination | Color0.1Lux@F1.2(AGC ON); black and white0.01Lux@F1.2(AGC ON) |
Electronic shutter | Auto(1/3 to 1/10000) | |
Day/Night switch | color/B&W/Light sensitive switch/Mixed mode switch | |
white balance | Auto / Lock white balance / fluorescent lamp /filament lamp /fluorescent lamp /HM | |
DNR | 2D and 3D DNR | |
WDR | Support 120DB Ture WDR | |
Video Adjust | Sharpness, Brightness, Saturation, Contrast, Chroma adjustable | |
image model | Transparent /real | |
color pattern | Standard /gorgeous | |
Corridor pattern | support | |
backlight compensation | support | |
FLC | support | |
penetrating fog | support | |
image distortion rectifying | support | |
Vernier focusing | support(-Z model support) | |
All electric rectifier | support(-Z model support) | |
Smart IR | support | |
Interfaces | Signal interface | one photosensitive resistance signal interface, one IR_CUT drive interface support photo resistance signal links to IR-CUT and IR light |
ICR driving voltage | 5V | |
Smart IR | One port | |
Reset interface | One port | |
Audio interface | One audio in; One audio out | |
Alarm interface | One alarm in; One alarm out | |
electric zoom interface | One port(-Z model support) | |
TTL interface | One port | |
CVBS interface | One port | |
Power interface | One DC12V power input | |
USB interface | One Port | |
POE interface | One Extended Interface | |
Network light interface | One Port | |
Network interface | One RJ45 10/100M Port | |
Functions | Motion detection | Multiple detection zones, variable sensitivity levels |
Capture function | JPEG,capture resolution is the max coding resolution | |
Security | Password protection and water marker | |
OSD | Support Channel Name and Time | |
Support custom character superposition | ||
Support image overlay | ||
storage | Support FTP storage | |
Smart function | Tripwire;Regional invasion;Items stolen;Items move;Density Detection;Number Stat;Through the fence ;Wandering detection ;Retrograde motion detection ;Face Capture | |
Smart alarm | Network abnormal, cover alarm etc. | |
Mobile client | VSSMOBILE for both iPhone and Android system phone | |
Protocol support | TCP/IP;UDP;HTTP;IGMP ;ICMP;DHCP;RTP/RTSP;DNS;DDNS;FTP;NTP;PPPOE;UPNP;SMTP;SNMP | |
Reverse the registered | support | |
Interface protocol | ONVIF2.6/CGI/GB28181 | |
General | Power Supply | DC12V/POE(-P) |
Power Consumption | <1.5W (without infrared lamp board) | |
Lightning Protection | Power , network, POE all lightning protection, meets with standard GB/T17626.5,and IEC61000-4-5 | |
IR_CUT pitch | 20mm | |
Size | 38*38(mm)Single Board |
