Starlight IP Camera,2MP Waterproof H.265 Camera,VSS Mobile App,Strong Light,ONVIF2.6
Starlight IP Camera,2MP Waterproof H.265 Camera,VSS Mobile App,Strong Light,ONVIF2.6
| Product Model: | RC-BF75P-2SW |
| FOB Price: | US$37.68-US$41.68 |
| Min. Order: | 1pc |
| Product Brand: | IdeaCamera |
| OEM/ODM: | Support |
| Warranty: | 2 Years |
| Country of Origin: | China |
| Certificate: | CE,FCC,ROHS |
| PDF: |  |
Model: RC-BF75P-2SW
Key features:
3.0-megapixel Starlight 3.6mm HD Fixed Lens (4, 6,8mm optional).
42pieces IR LEDs, 40 meters of IR distance.
White casing with strong bracket.
Normal network video cable.
Internal POE (Optional).
Product characteristics:
1/2.8” CMOS Sensor (Sony IMX307+Hi3516C V300).
Support H.264/H.265/H.265+ Video compression.
Support Starlight (Day and night all color).
Standard 38*38 single board, Easy to install CCTV Camera.
Support smart IR (Day and night auto switch).
Max video resolution: 1920*1080@25/30fps.
Support 1ch audio input, 1ch audio output, realize two-way phonetic dialogue.
Support 1ch alarm input.
Support 1 USB reserve interface.
Support 1ch CVBS output.
Support three-bit stream.
Support 3D noise reduction and digital WDR.
Support private network penetration and cross browser access.
Mobile APP name: VSS Mobile.
Support POE power supply (optional).
Product Advantages:
Offer 2-years product warranties.
Logistics convenient.
OEM/ODM.
CCC/CE/FCC Certified.
Strict product quality control.
Efficiently working with almost NVR.
Lower price.
6-8 working day per order.
Product applications:
This is the best product of safety field. It and hard disk video recorders、cable、power supply、display、etc. Constitute a complete security system. Tts application is more extensive. Such as homes、factories、highways、office building、garden、community, or a large public places, etc.
2MP WD&SL Single-Boards IP Camera Module | ||
Product model | RC-BF75P-2SW | |
System Structure | DSP | Embedded RTOS, DSP (Hi3516C V300) |
Sensor | 1/2.8" CMOS sensor (SONY IMX307) | |
Video Encoding | Video Encoding | H.265/ H.264High Profile/Main Profile/ Base Line Profile/ MJPEG |
H.265+/ H.264High Profile+/Main Profile+/ Base Line Profile+ | ||
Maximum Image Output | Main stream：1920*1080@25/30fps; Auxiliary stream 1: 704*576@25/30fps； Auxiliary stream 2: 1280*720@14/3fps ； | |
Streaming transmission | Three stream | |
Video Bite rate | 32Kbps~8MKbps | |
Image Enhancement | Min. illumination | Color0.1Lux@F1.2（AGC ON）； black and white0.01Lux@F1.2（AGC ON） |
Electronic shutter | Auto（1/3 to 1/10000） | |
Day/Night switch | color/B&W/Light sensitive switch/Mixed mode switch | |
white balance | Auto / Lock white balance / fluorescent lamp /filament lamp /fluorescent lamp /HM | |
DNR | 2D and 3D DNR | |
WDR | Support 120DB Ture WDR | |
Video Adjust | Sharpness, Brightness, Saturation, Contrast, Chroma adjustable | |
image model | Transparent /real | |
color pattern | Standard /gorgeous | |
Corridor pattern | support | |
backlight compensation | support | |
FLC | support | |
penetrating fog | support | |
image distortion rectifying | support | |
Vernier focusing | support（-Z model support） | |
All electric rectifier | support（-Z model support） | |
Smart IR | support | |
Interfaces | Signal interface | one photosensitive resistance signal interface, one IR_CUT drive interface support photo resistance signal links to IR-CUT and IR light |
ICR driving voltage | 5V | |
Smart IR | One port | |
Reset interface | One port | |
Audio interface | One audio in; One audio out | |
Alarm interface | One alarm in; One alarm out | |
electric zoom interface | One port（-Z model support） | |
TTL interface | One port | |
CVBS interface | One port | |
Power interface | One DC12V power input | |
USB interface | One Port | |
POE interface | One Extended Interface | |
Network light interface | One Port | |
Network interface | One RJ45 10/100M Port | |
Functions | Motion detection | Multiple detection zones, variable sensitivity levels |
Capture function | JPEG，capture resolution is the max coding resolution | |
Security | Password protection and water marker | |
OSD | Support Channel Name and Time | |
Support custom character superposition | ||
Support image overlay | ||
storage | Support FTP storage | |
Smart function | Tripwire；Regional invasion；Items stolen；Items move；Density Detection；Number Stat；Through the fence ；Wandering detection ；Retrograde motion detection ；Face Capture | |
Smart alarm | Network abnormal, cover alarm etc. | |
Mobile client | VSSMOBILE for both iPhone and Android system phone | |
Protocol support | TCP/IP；UDP；HTTP；IGMP ；ICMP；DHCP；RTP/RTSP；DNS；DDNS；FTP；NTP；PPPOE；UPNP；SMTP；SNMP | |
Reverse the registered | support | |
Interface protocol | ONVIF2.6/CGI/GB28181 | |
General | Power Supply | DC12V/POE(-P) |
Power Consumption | <1.5W (without infrared lamp board) | |
Lightning Protection | Power, network, POE all lightning protection, meets with standard GB/T17626.5，and IEC61000-4-5 | |
IR_CUT pitch | 20mm | |
Size | 38*38（mm）Single Board | |
